FINGERTEC Card Access Control & Time Attendance
Model :Kadex+
| MODEL | Kadex+ |
| SURFACE FINISHING | Glass with metal frame |
| TYPE OF ANTENNA | RFID |
| MICROPROCESSOR | 1GHz Dual Core CPU |
| MEMORY | DDR2 64M, Flash 256M |
| PUSH TECHNOLOGY | Yes |
| PRODUCT DIMENSION (L X W X H), mm | 85 x 19.8 x 143 |
| STORAGE | |
| • Card | 50,000 |
| • Transaction logs | 200,000 |
| ENROLLMENT & VERIFICATION | |
| • Methods | Card & password |
| • Card per user ID | 1 |
| • Reading distance, mm | 30 (RFID) |
| • Verification time (sec) | < 1s |
| CARD TECHNOLOGY | |
| • RFID: ISO 7816, 64-bit, 125kHz | Yes |
| • MIFARE: ISO 14443-A, MFIS50/S70, 13.56MHz | Made to order |
| • HID: HID 1326, 26-bit, 125kHz | Made to order |
| COMMUNICATIONS | |
| • Method | TCP/IP, Wiegand (slave reader), RS485 (slave reader), RS232 (only for printer) |
| • Baud rates | 9600, 19200, 38400, 57600, 115200 |
| • Wiegand | 26 to 34 bit |
| OPERATING ENVIRONMENT | |
| • Temperature (°C) | -10 ~ 55 |
| • Humidity (%) | 10 ~ 90 |
| • Power input | DC 12V 2A |
| MULTIMEDIA | |
| • Voice | Yes |
| • Display | 2.4” touch keypad |
| ACCESS CONTROL | |
| • EM lock driving output | Yes |
| • Alarm output/Auxiliary input | Yes |
| • Exit button/door sensor | Yes |
| VOICE / DISPLAY LANGUAGE (TERMINAL) | English (Standard), Arabic, Indonesian, Persian, Portuguese, Spanish, Traditional Chinese, Vietnamese. Other languages are available upon request. |
