CODESOFT Desktop Barcode Printer
Model: Easybar 4eZ
FEATURES
Powerful
– High print speed up 8inchsec for 203dpi
– Supported 1 inch or 0.5 inch inner core ribbon
– Supported 300 meter ribbon roll and 5 inch label roll
– 8MB Flash ROM, 16MB SDRAM
Efficient
– Wide range movable reflective paper sensor
Convenient
– Easy paper and ribbon loading
– Fashion elegant appearance and color
- Weight : 2.62kg
- Humidity : 5% to 85% (non-condensing)
- Printing Method : Direct Thermal & Thermal transfer
- Printing Speed : 4E: 8 IPS(203.2mm/s) ; 4i: 6 IPS(152.4mm/s) 300 DPI(4 IPS)
- Dimensions (W*D*H) : 208 X 310 X 195 mm
- Memory : 8MB Flash ROM, 16MB SDRam
- Operating Temperature : 0 to 40 degree Celsius
- Storage Temperature : -40 to 60 degree Celsius
- Resolution : 203 DPI (8 dots/mm)
- Maximum Print Speed : 6 IPS(152.4 mm/s)
- Maximum Print Width : 4.09?(104 mm)
- Maximum Print Length : 157.5?(4000mm)
- Memory : 2 MB FLASH ROM, 2 MB SDRAM
- Media : Roll-feed, die-cut, continuous, fan-fold, tags, tickets in plain paper or thermal paper Width:4.5?(114 mm) max.,0.8?(20 mm)min. Supply roll: OD 5?(127 mm) max., ID 1?(25.4 mm) min. Thickness: 0.08~0.20mm(0.003?~0.0078?), including liner
- Ribbon : Ribbon Width: 110mm~300M; Ribbon Roll Diameter: ID 1" (25.4mm) ~ OD 2.75" (70mm); Ribbon Length: 110mm ~300M; Ribbon Type: Wax, Wax/Resin, Resin
- Media Sensor : Adjustable reflective & transmissive
- Barcode Types : 1D Barcode : Code 39,Code 93,Code 128,Codabar,EAN-8/13/128,Interleave 2 of 5,UCC-128,UPC A/E 2 and 5 add-on, etc. 2D Barcode : Data Matrix, MaxiCode, PDF417,QR, etc.
- Interfaces : RS-232 serial, USB
- Power Rating : 24 VDC, 2.5A
- Operation Environment : Temperature: 32° F ~ +104° F (0° C ~ 40° C) Relative humidity: 5% – 85% non condensing
- Storage Environment : Temperature: -40° F ~ +140° F (-40° C ~ 60° C) Relative humidity: 5% – 85% non condensing
- Optional Items : Peeler kit, Internal 100/10 M Ethernet Interface card
- Input : AC 100~240 V, 47~63 Hz
- Output : DC 24 V, 2.5 A
- Environment : 0° C ~ 40° C
